BALLAST SPECIFICATIONS
Ballast
Xenlight is
the new top quality ballast, for 21W/35W/50W H.I.D-High Intensity
Discharge high-pressure xenon arc tubes for 12V/24V. The Ballasts
are standards based, dedicated to different markets:
+ Automotive Market
- All Vehicles markets including Europe and the USA vehicle markets and
after market
+ Aviation - Landing and Taxi lights, hangars, working places.
+ Medical Devices – Fiber optics and UV bulbs.
+ Homeland Security, Search & Rescue markets – Utility lights for search
& rescue, law enforcements etc' with no risk of electric shock.
+ Luxury/Sports/Entertainment markets - Under water lights for Yachting,
Diving, Fishing, 4x4 Vehicles travels and search lights, Camping,
Hunting.
+
Technology protected by Strong Patent (PCT) – Patented:
EP-0 301 436 B1,
USP-4,922,396, DE-196 27 989 A1, DE-43 12 300 A1
Electrical Specifications for 12V ballasts:
XLS
– Square version.
XLR – Round version.
35/50 – Output wattage.
12/24 – Input voltage
| XLS/XLR 3512 | XLR5012 | |
| Normal operating input voltage range | 9V - 16V | 9V - 16V |
| Time limited extended operating input voltage range | 6V - 18V | 6V - 18V |
| Starting input voltage range | 8.5V - 18V | 8.5V - 18V |
| Nominal output power | 34.5W ± 1W | 49W ± 2W |
| Low output power setting | 25W ± 1W | 25W ± 1W |
| Maximum run up output power | 75W | 50W |
| Maximum run up lamp amperes | 2.9A | 4.2A |
| Maximum inrush current at 13.5 V | 8A | 5.3A |
| Max inrush current 13.5 V low power level | 3.2A | 3.2A |
| Efficiency of D1S and ballast at nominal supply | 85% | 87% |
| Ballast unit efficiency | 87.5% | 88% |
| Output steady state frequency | 4.6KHz | 4.6KHz |
| Operating temperature range | - 40 to +105oC | - 40 to +105oC |
Electrical Specifications for 24V ballasts:
| XLS/XLR 3524 | XLR5024 | |
| Normal operating input voltage range | 22V - 29V | 22V - 29V |
| Extended operating input voltage range | 16V - 32V | 16V - 32V |
| Starting input voltage range | 22V - 32V | 22V - 32V |
| Nominal output power | 34.5W ± 1W | 49W ± 2W |
| Low output power setting | 25W ± 1W | 25W ± 1W |
| Maximum run up output power | 75W | 50W |
| Maximum run up lamp amperes | 1.7A | 2.3A |
| Maximum inrush current at 13.5 V | 4A | 2.7A |
| Max inrush current 13.5 V low power level | 1.6A | 1.6A |
| Efficiency of D1S and ballast at nominal supply | 86% | 87% |
| Ballast unit efficiency | 89% | 89% |
| Output steady state frequency | 4.6KHz | 4.6KHz |
| Operating temperature range | - 40 to +105oC | - 40 to +105oC |
